Toshiba B-EX4T3 Series User Manual

4. PRINTER SPECIFICATIONS ENGLISH VERSION EO1-33114
25
4. PRINTER SPECIFICATIONS
This section describes the printer specifications.
Model
Item
B-EX4T3-HS12-QM/CN-R
Dimension (W x D x H) 278 mm x 460 mm x 310
m
m (10.9” x 18.1” x 12.2”)
Weight (kg) 17 kg
Operating temperature range 5 degC to 40 degC (40 degF to 104 degF)
Relative humidity 25% to 85% RH (no condensation)
Power supply Universal switching power source AC 100 V to 240 V, 50
/
60 Hz +
/
- 10%
Input voltage AC100 V to 240 V, 50/60 Hz +
/
- 10%
Power
Consumption
During a print job* 110W
During stand-
b
y 15W or less
During sleep mode 4.7W
Resolution
600 dpi
(
23.6 dots/mm
)
Printing method Thermal transfe
r
Printing speed 50.8 mm/sec. (2 inches/sec.)
76.2 mm/sec. (3 inches/sec.)
101.6 mm/sec. (4 inches/sec.)
127.0 mm/sec. (5 inches/sec.)
152.4 mm/sec. (6 inches/sec.)
Available media width (including
b
acking paper)
25.0 mm to 110 mm (0.98 inches to 4.33 inches)
Effective print width (max.) 104.0 mm (4.1 inches)
Issue mode Batch
Strip (Strip mode is enabled only when the optional Strip Module is
installed.)
Cut (Cut mode is enabled only when the optional Cutter Module is
installed.)
LCD Message display Graphic type 128 x 64 dots
*: While 20% slant lines are printed in the specified format.
