5. SUPPLY SPECIFICATIONS ENGLISH VERSION EO1-33114
5.1 Media
29
5.1.2 Detection Area of the Transmissive Sensor
The Transmissive Sensor is movable from the center to the left edge of media.
The Transmissive Sensor detects a gap between labels, as illustrated below.
NOTE:
Round holes are not acceptable.
(Min. 3.0mm
when the cutter
is used)
11m
m
