5. SUPPLY SPECIFICATIONS ENGLISH VERSION EO1-33114
5.1 Media
28
B-EX4T3-HS
Batch Cutter Peel-off (*1)
① Pitch
Min. 5mm 25mm 5mm
Max. 500mm 500mm 256mm
② Label Length
Min. 3mm
Max. 498mm 497mm 254mm
③ Backing paper
Width
Min. 25mm
Max.
110mm
④ Label Width
Min.
13mm
Max.
108mm
⑤ Gap
Min. 2mm 3mm 2mm
Max. 20mm
⑥ Black mark
length
Min. 2mm 3mm 2mm
Max. 20mm
⑦ Effective print
Width
Max. 104mm
⑧ Effective print
Length
Min. 3mm
Max. 498mm 497mm 254mm
⑨ Print speed
up/slow down area
Slow up 1mm
Slow down 1mm
Thickness
Min. 0.13mm
Max. 0.17mm
Max. outer roll diameter
Φ200mm(Φ180, When using built-in
Rewinder) *Φ170, when paper tube inner
diameterφ50.8
Roll-up method
Inner ・Outer
Paper core
ID φ76.2±0.3mm
(*1) When using the High precision peel-off module（B-EX904-HH-QM-R）.
NOTES:
1. To ensure print quality and print head life use only Toshiba Tec specified media.
2. When the Disc cutter is used, the minimum label length shall be 18.0 mm – (Gap length/2) or longer.
3. The ratio of a label length to a gap length must be a minimum of 3 to 1 (3:1).
4. When using label stock in cut mode, be sure to cut in the gaps. Cutting labels will cause the adhesive to stick to
the cutter, which may affect the cutter performance and shorten the cutter life.
