1. PRODUCT OVERVIEW ENGLISH VERSION EO1-33114
1.5 Appearance
4
1.4.4 Operation Panel
1.4.5 Interior
Please see Section 3 for further information about the Operation Panel.
LCD
ERROR LED
PAUSE
RESTART
UP
RIGHT
ENTER
DOWN
CANCEL
MODE
LEFT
FEED
ONLINE LED
Damper
Ribbon Shaft
Supply Shaft
Locking Ring
Supply Holder
Ribbon shaft holder
Head Lever
Ribbon Stopper
Print head
Warning
High temp
