2. SUPPLY SPECIFICATIONS EO10-33016A
(Revision Date: Feb. 14, 2008)
2.4 Specification of RFID Tag
2- 8
(1) UPM Raflatac’s Rafsec Short Dipole 2 Tag
It is recommended to locate the vertical center of an RFID tag at 27 mm ± 3 mm from a leading edge of a
label and align the horizontal center with the horizontal center of the label.
27mm±3mm
Media feed direction
