1.1.3 Interior View
1.2 Indications in Model No.
B − S V 4 T− G S 10−QM
Destination code
QM: Worldwide
Interface
10: USB, RS-232C, Centronics
Printer type
S: Standard
C: Cutter
Resolution
G: 8 dots/mm
Print method
T: Thermal direct or Thermal transfer
Print width
4: 4 inches
Media Guide/
Feed Gap Sensor
Black Mark Sensor
Print Head
Media Hold Shaft
Cover Open
Senso
r
Caution Symbol for the
Print Head (Please refer
to WARNING!)
Top Cover Support
Platen
Rear Hub
Front Hub
Strip Plate
Ribbon Access
Ribbon Senso
r
Media Guide
WARNING!
Do not touch the print head o
r
around it just after printing.
You may get burned as the
p
rint head becomes very hot
during printing.
Fig.2 Interior View
