1-3
1.3 Specification
1.3.1 Printer
Item B-SV4T
Mechanism
Resolution 203 dpi.
Max. Print Width 108 mm.
Max. Print Length 609.6 mm ( 24” ).
Ribbon Capacity 300 meter with 1” core. (Max. Outside diameter: 67 mm)
Printing Speed 2, 3, 4 and 5 ips selectable.
Strip function 2, 3 ips selectable
Printing Method Direct thermal and thermal transfer printing.
Enclosure
Structure
Dimension
Operation Panel
Double-walled plastic.
Standard Model: 314mm(L) x 213mm(W) x 188mm(H)
One push switch, and one indicator LED (Green,
Orange, Red colors).
Hardware
Sensor Transmissive sensor (offset 6 mm from liner
edge).
Reflective sensor (position adjustable).
Head open sensor.
Ribbon sensor
Memory 1M byte Flash memory
2M bytes DRAM
Interface RS-232C (max baud rate, 57600 bps).
USB: V1.1.
Centronics SPP mode.
Power AC input: 100-240V universal auto switching power supply.
DC output: 24V 3.75A.
Firmware
Font Type 8 alpha-numeric bitmap fonts, and 1 true type font.
Rotation 0, 90,180 and 270 degrees.
Barcode Format Code 39, Code 93, Code 128UCC, Code128 subsets A.B.C, Codabar,
Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and
UPC2(5) digits add-on, MSI, PLESSEY, POSTNET, PDF-417, Maxicode,
DataMatrix., Reduced Space Symbology (RSS)
Command Set TPCL
Environment
Operation Temperature: 5
°C
~ 40
°C
.
Relative Humidity: 25% ~ 85% (Non Condensing).
Storage Temperature: -40
°C
~ 60
°C
.
Relative Humidity: 10% ~ 90% (Non Condensing).
