Toshiba BMS-CT2560U-E - Confirm Power Consumption Graph

Touch Screen Controller Owner's Manual
74
-EN
Pulse values are graphed and the electric power can be visually confirmed.
* This function can be displayed when the electric power is measured by connecting this Unit to a pulse transmission type watt
hour meter.
● NOTE
Confirm the Power Consumption on a Graph
1 Tap
[1-(1)] appears.
2 Tap [2-(1)]
3 Tap the data type to be displayed
4 To select [3-(3)] or [3-(4)], set the check box of the watt
hour meter to sum to and tap [
4-(1)]
An electric power graph is displayed.
2
-(1)
2
-(1)
1
-(1)
1
-(1)
3
-(1)
3
-(1)
3
-(2)
3
-(2)
3
-(3)
3
-(3)
3
-(4)
3
-(4)
3-(1) All systems
(Daily):
You can display the total electric power on a
daily basis on a graph.
3-(2) All systems
(Monthly):
You can display the total electric power on a
monthly basis on a graph.
3-(3) Select System
(Daily):
You can select the watt hour meter to sum and
display the daily electric power on a graph.
3-(4) Select System
(Monthly):
You can select the watt hour meter to sum and
display the monthly electric power on a graph.
4
-(1)
4
-(1)
Tap to change the summary period to display. You can also tap the
displayed date to display the calendar and change the summary period.
