1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Jam 23
1 TROUBLESHOOTING FOR THE HARDWARE
10
Close the automatic duplexing unit.
Paper jam in the Job Separator and the Offset Tray (both optional)
The procedure below is only for e-STUDIO205L/255/305 with the Job Separator or the Offset Tray installed and not valid
for e-STUDIO355/455 with the Job Separator installed.
y Be careful not to let your fingers be caught between the equipment and the duplexing unit or automatic
duplexing unit.
This could injure you.
y Do not touch the fuser unit or the metal portion around it.
Since they are very hot, you could be burned or the shock could cause you to get your hand injured in the machine.
9
Close the transport guide holding the green knob.
1
Open the automatic duplexing unit.
2
Open the Job Separator cover or the Offset Tray
cover.
3
Remove paper jammed inside of the Job Separator or
the Offset Tray.
To Next Page
