45
Monitor Function
liatedyalpsiD30WS20WS10WS
3
1
1~3
AError data
[U.
], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B Check code is displayed (latest one only).
If there is no check code: [– – –].
2
Type of compressor installed A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B
3
Outdoor unit HP capacity A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B
8HP: [… 8], 10HP: [… 10], 12HP: [… 12],
14HP: [14], 16HP: [16] , 18HP: [18], 20HP: [20], 22HP: [22]
4
Compressor operation command A
[U.
], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B Indicates which compressor is ON.
Any unconnected compressors is represented by “–”. B
1 0 NOsi1.oNrosserpmocnehW
0 1NOsi2.oNrosserpmocnehW
5
Fan operation mode A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B At rest: [F … 0], In mode 63: [F 6 3]
6
Release signal A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B Normal: [r … …], Upon receiving release signal: [r … 1]
7
Oil level judgment A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B Normal: [… … …], Low level: [… … L]
8
Compressor 1 operating current A
[U. ], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B [
. ], . is value of operating current in decimal format.
9
Compressor 2 operating current A
[U.
], : SW03 setting No. + 1 (Outdoor unit No. U2 to U 3)
B [
. ], . is value of operating current in decimal format.
SW03 7-segment display section A
1 U2
2 U3
* This method is used when displaying follower unit information on the 7-segment display of the header unit.
Note: Follower unit is selected by setting SW03.
(4) Display of Outdoor Cycle Data (Display at Header Unit)
