Refrigerant Piping
skrameRezis epip fo noitceleSemaNstrap gnipiP.oN
(5)
Branching section
↓
Indoor unit
Indoor unit
connecting pipe
Connecting pipe size of indoor unit
edis saGknar yticapaC
Liquid
side
007 to 012 type
15m or less real length Ø9.5 Ø6.4
Real length exceeds 15m Ø12.7 Ø6.4
4.6Ø7.21Øepyt 810 ot 510
5.9Ø9.51Øepyt 650 ot 420
7.21Ø2.22Øepyt 690 ot 270
(6)
Branching section
Y-shaped
branching joint
Selection of branching section (Y-shaped branching joint)
Total capacity code of indoor units
Model name
Equivalent to HP
Equivalent to
capacity
Y-shape
branching joint
Below 6.4 Below 18.0 RBM-BY55E
6.4 to below 14.2 18.0 to below 40.0 RBM-BY105E
14.2 to below 25.2 40.0 to below 70.5 RBM-BY205E
25.2 or more 70.5 or more RBM-BY305E
(7)
Branching section Branching header
Selection of branching section (Branching header)
Total capacity code of indoor units
Model name
Equivalent to HP
Equivalent to
capacity
*2
Branching header
For 4
branches
Below 14.2 Below 40.0 RBM-HY1043E
14.2 to below 25.2 40.0 to below 70.5 RBM-HY2043E
For 8
branches
Below 14.2 Below 40.0 RBM-HY1083E
14.2 to below 25.2 40.0 to below 70.5 RBM-HY2083E
*2: Up to a total of 6.0 maximum equivalent to HP capacity codes is connectable to one line
after branching of heade
r. When the total capacity codes of all outdoor units are 12 to
below 26 (equivalent to HP) and you use a branching header for the first branching
section, use a RBM-HY2043E or RBM-HY2083E regardless of the total capacity codes
of outdoor units at downstream side. In addition, you cannot use a branching header for
the
first branching section when the total capacity codes of all outdoor units are ov
er
26 (equivalent to HP).
(8)
Branching section
Outdoor unit
connection piping
kit (For linking of
outdoor units)
Outdoor unit connection piping kit (For linking of outdoor units)
Total capacity code of outdoor units
*3
Model name
Equivalent to HP
Equivalent to
capacity
Outdoor unit
connection piping kit
(For linking of outdoor
units)
Below 26.0 Below 73.0 RBM-BT14E
26.0 or more 73.0 or more RBM-BT24E
*3: Downstream side when regarding the main piping as the start point
↓
Pipe size differs
(4)
Branching section
Branching section
Branching pipe
Pipe size between branching sections
Total capacity codes of
indoor units at downstream side
Gas side
Liquid
side
Equivalent to HP
Equivalent to
capacity
below 2.4 below 6.6 Ø12.7 Ø9.5
2.4 to below 6.4 6.6 to below 18.0 Ø15.9 Ø9.5
6.4 to below 12.2 18.0 to below 34.0 Ø22.2 Ø12.7
12.2 to below 20.2 34.0 to below 56.5 Ø28.6 Ø15.9
20.2 to below 22.4 56.5 to below 62.5 Ø28.6 Ø19.1
22.4 to below 25.2 62.5 to below 70.5 Ø34.9 Ø19.1
25.2 to below 35.2 70.5 to below 98.5 Ø34
.9 Ø19.1
35.2 or more 98.5 or more Ø41.3 Ø22.2
based on the total
capacity code value
of indoor units at the
downstream side.
If the total capacity
code value of indoor
units exceeds that
of the outdoor units,
apply the capacity
code of the outdoor
units.
<Cooling,Heat pump type>
To Next Page
