E6581697
F-100
6
Title Function Adjustment range
Reference
of maximum
value of
f677
Default
setting
f677
Maximum numbers of
pulse train
0.50-2.00 (kpps)
– 0.80
f678
Pulse train output filter 2-1000 (ms)
–
64
, Digital panel meter for reference
Type: K3MA-F (OMRON)
Connection terminal: OUT-E4, NO-E5
Note 1: When item of
f676 reaches “Reference of max. value”, the number of pulse train set by f677
are sent to output terminals (OUT)
Note 2: The ON pulse width is maintained constant.
The ON pulse width is fixed at a width that causes the duty to reach 50% at the maximum pulse
number set with
f677.
Therefore, the duty is variable.
For example, the ON pulse width is approximately 0.6 ms when
f677=0.80,
approximately 0.5 ms when
f677=1.00,
approximately 0.3 ms when
f677=1.60.
Note 3: The minimum pulse output rate is 10pps. Keep in mind that no pulses can be put out at any rate
smaller than this.
Note 4:
f676 = 12 is the motor drive frequency.
6.28.2 Calibration of analog output
f681 : Analog output signal selection
f684 : Analog output filter
f691 : Inclination characteristic of analog output
f692 : Analog output bias
Function
Output signal from the FM terminal can be switched between 0 to 1mAdc output, 0 to 20mAdc output,
and 0 to 10Vdc output with the
f681 setting. The standard setting is 0 to 1mAdc output.
* Optional frequency meter: When using QS60T, set
f681=0 (meter option (0 to 1mA) output).
