Toshiba TOSVERT VF-MB1 User Manual

E6581697
F-101
6
[Parameter setting]
Title Function Adjustment range Default setting
f681
Analog output signal selection
0: Meter option (0 to 1mA)
1: Current (0 to 20mA) output
2: Voltage (0 to 10V) output
0
f684
Analog output filter
2-1000 (ms) 2
f691
Inclination characteristic of analog
output
0: Negative inclination (downward slope)
1: Positive inclination (upward slope)
1
f692
Analog output bias -1.0 - +100.0 (%) 0.0
Note 1: With 0 to 20mAdc (4 to 20mAdc) output, or 0 to 10Vdc output, set f681 to 1 or 2.
■ Example of setting
f681=1, f691=1, f692=0(%) f681=1, f691=1, f692=20(%)
0
20
(mA)
0100%
Internal calculated v
alue
4
20
(mA)
0100%
f692
O
u
t
p
u
t
c
u
r
r
e
n
t
Internal calculated value
f681=1, f691=0, f692=100(%) f681=1, 691=0, f692=100(%)
0
20
(mA)
0100%
: Large gain
O
u
t
p
u
t
c
u
r
r
e
n
t
Internal calculated value
4
20
(mA)
0100%
: Small gain
f692
O
u
t
p
u
t
c
u
r
r
e
n
t
Internal calculated value
, The analog output inclination can be adjusted using the parameter .
