Toshiba TOSVERT VF-MB1 User Manual

E6581697
F-117
6
■ Trace data communication number
Communication
No.
Function
Minimum setting
/readout unit
Setting/readout range
Default
setting
E000 Trace data 1~4 pointer 1/1 0~99 0
E100 Data 1 of trace data 1 1/1 0~ffff 0
 Data 2~99 of trace data 1 1/1 0~ffff 0
E199 Data 100 of trace data 1 1/1 0~ffff 0
E200 Data 1 of trace data 2 1/1 0~ffff 0
 Data 2~99 of trace data 2 1/1 0~ffff 0
E299 Data 100 of trace data 2 1/1 0~ffff 0
E300 Data 1 of trace data 3 1/1 0~ffff 0
 Data 2~99 of trace data 3 1/1 0~ffff 0
E399 Data 100 of trace data 3 1/1 0~ffff 0
E400 Data 1 of trace data 4 1/1 0~ffff 0
 Data 2~99 of trace data 4 1/1 0~ffff 0
E499 Data 100 of trace data 4 1/1 0~ffff 0
Ex.) When operation frequency data is acquired through a communication device
Data acquired (
1f40) h=8000  8000×0.01Hz=80.0Hz
■ Relationship between pointer and data
The table below shows the relationship between pointer (E000 set value) and trace data (1 to 4).
Pointer (E000 set value)
0 1 2 - 98 99
Trace data 1（E100～E199） E100 E101 E102 - E198 E199
Trace data 2（E200～E299） E200 E201 E202 - E298 E299
Trace data 3（E300～E399） E300 E301 E302 - E398 E399
Trace data 4（E400～E499） E400 E401 E402 - E498 E499
<Example of setting> If E000 is set to 2:
(Earliest data) (Latest data)
Trace data 1 E102 ~ E199, E100, E101
Trace data 2 E202 ~ E299, E200, E201
Trace data 3 E302 ~ E399, E300, E301
Trace data 4 E402 ~ E499, E400, E401
Note 1: Use the parameters f742 through f745 to specify the types of trace data (1 to 4).
Note 2: Communication numbers E000 is automatically incremented by the inverter when data is traced
continuously.
* In ordinary cases, these parameters do not need to be rewritten.
