Toshiba TOSVERT VF-MB1 User Manual

E6581697
A-12
1
Note1) Bend the clips on the wiring port of the terminal cover to connect the PB, PBe, PA/+, and PC/-
terminals.
Note2) Be careful to insert all wires into the cage of terminal block.
VFMB1-4055, 4075PL
VFMB1-4110, 4150PL
M4 screw
Earth terminals
(M5 screw)
M4 screw
M4 screw
Earth terminals
(M5 screw)
M4 screw
Grounding
capacitor
switch
Grounding
capacitor
switch
