Toshiba TOSVERT VF-MB1 User Manual

E6581697
A-11
1
PBe PB U/T1 V/T2 W/T3
R/L1 S/L2 T/L3
PBe PB U/T1 V/T2 W/T3
R/L1 S/L2 T/L3
VFMB1-4004 to 4015PL VFMB1-4022, 4037PL
VFMB1S-2002 to 2022PL,
VFMB1-4004 to 4037PL
<Top view>
M3 screw
Earth terminal
(M4 screw)
EMC plate
M3 screw
M3 screw
Earth terminal
(M4 screw)
EMC plate
M3 screw
DC bus connectors
(PA / +, PC / -)
Earth terminals
(M5 screw)
Grounding capacitor switch
PC / -
PA / +
