 List of logic input terminal function settings
Parameter
programmed value
Parameter
programmed value
Positive
logic
Negative
logic
Function
Positive
logic
Negative
logic
Function
No function   Factory specific coefficient *1
Forward run command   Integrating wattmeter (kWh) display
clear
Reverse run command   Trace back trigger signal
Standby   Light-load high-speed operation
prohibitive signal
Reset command   Holding of RY-RC terminal output
    Preset-speed command 1   Holding of OUT-NO terminal output
    Preset-speed command 2   Frequency UP *2
    Preset-speed command 3   Frequency DOWN *2
    Preset-speed command 4   Clear frequency UP/DOWN *2
    Jog run mode   Coast stop command
    Emergency stop by external signal   Forward/reverse selection
    DC braking command   Run/Stop command
    2nd acceleration/deceleration   Frequency reference command forced
switching
    3rd acceleration/deceleration   Frequency setting mode terminal board
    2nd V/F control mode switching   Command mode terminal board
    2nd stall prevention level   Parameter editing permission
    PID control prohibition   Fast stop command 1
    External thermal error input   Fast stop command 2
    Forced local from communication   Traverse permission signal
    Operation hold (hold of 3-wire operation)   Factory specific coefficient *1
    PID integral/differential clear   Forward deceleration
    PID characteristics switching   Forward stop
    Forced run operation   Reverse deceleration
    Fire speed operation   Reverse stop
    Acceleration/deceleration suspend
signal
 to  Factory specific coefficient *1
    Power failure synchronized signal   Parameter editing prohibition
    Logic sequence function trigger signal   Parameter reading prohibition
*1: Factory specific coefficients are manufacturer setting menus. Do not change the value of these parameters.
*2: Active when  (frequency setting mode selection) =  (UP/DOWN from external logic input) is set.
The frequency setup range is from  to  (upper limit frequency). The acceleration/deceleration time
relative to the set frequency is / while the acceleration/deceleration speed is not switched.
☆ Refer to section 11.6 for details about the input terminal function.
