E6581697
G-7
7
Assign one type of function to an output terminal
Terminal
symbol
Title Function Adjustment range Default setting
RY-RC

Output terminal selection 1A 4 (Low-speed detection signal)
OUT  Output terminal selection 2A
6 (Output frequency
attainment signal)
FL
(A, B, C)
 Output terminal selection 3
0 - 255
10 (Fault signal)
Note 2) When assigning 1 type of function to the RY-RC terminal, set only .
Leave parameter  as the standard setting ( = ).
Note 3) When assigning 1 type of function to the OUT terminal, set only .
Leave parameter  as the standard setting ( = ).
Assign two types of functions to the output terminal (RY-RC, OUT)
Terminal
symbol
Title Function Adjustment range Default setting
RY-RC

Output terminal
selection 1A
4 (Low-speed detection
signal)
OUT

Output terminal
selection 2A
6 (Output frequency
attainment signal)
RY-RC

Output terminal
selection 1B
OUT

Output terminal
selection 2B
0 - 255
255 (Always ON)
0:  and 
 and 
1:  or 
 and 
2:  and 
 or 
RY-RC, OUT 
Output terminal logic
selection
3:  or 
 or 
0
Note 4)  and  are active only when  = : Logic output (default).
Function is inactive when  = : Pulse train output is set.
