E6581697
K-8
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0209 Analog input filter ms 1/1 2-1000
64
6.6.2
7.3

0210 VIB input point 1
setting
% 1/1 -100-+100 0

0211 VIB input point 1
frequency
Hz 0.1/0.01 0.0-500.0 0.0

0212 VIB input point 2
setting
% 1/1 -100-+100 100

0213 VIB input point 2
frequency
Hz 0.1/0.01 0.0-500.0 *1

0214 VIB input point 1
rate
% 1/0.01 -250-+250 0 6.26
6.27

0215 VIB input point 2
rate
% 1/0.01 -250-+250 100

0216 VIC input point 1
setting
% 1/1 0-100 0 6.6.2
7.3

0217 VIC input point 1
frequency
Hz 0.1/0.01 0.0-500.0 0.0

0218 VIC input point 2
setting
% 1/1 0-100 100

0219 VIC input point 2
frequency
Hz 0.1/0.01 0.0-500.0 *1

0220 VIC input point 1
rate
% 1/0.01 0-250 0 6.26

0221 VIC input point 2
rate
% 1/0.01 0-250 100

0239 Factory specific
coefficient 2A
- - - -
* 3

0240 Starting frequency Hz 0.1/0.01 0.1-10.0 0.5 6.7.1

0241 Operation starting
frequency
Hz 0.1/0.01 0.0- 0.0 6.7.2

0242 Operation starting
frequency
hysteresis
Hz 0.1/0.01 0.0- 0.0

0249 PWM carrier
frequency during
DC braking
kHz 0.1/0.1 2.0-16.0 4.0 6.8.1

0250 DC braking
starting frequency
Hz 0.1/0.01 0.0- 0.0

0251 DC braking
current
%(A) 1/1 0-100 50

0252 DC braking time s 0.1/0.1 0.0-25.5 1.0

0254 Motor shaft fixing
control
- - 0: Disabled
1: Enabled (after DC braking)
0 6.8.2

0256 Time limit for
lower-limit
frequency
operation
s 0.1/0.1 0: Disabled
0.1-600.0
0.0 6.9.1

0257 Factory specific
coefficient 2B
- - - -
* 3

0258 Factory specific
coefficient 2C
- - - -
* 3
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
