Toshiba TOSVERT VF-MB1 User Manual

E6581697
K-17
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0614 Ground fault
detection selection
- -
0: Disabled
1: Enabled
1 6.24.9

0615 Over-torque
trip/alarm
selection
- - 0: Alarm only
1: Tripping
0

0616 Over-torque
detection level
%
1/0.01 0 (disabled)
1-250
150

0618 Over-torque
detection time
s 0.1/0.1 0.0-10.0 0.5
6.24.10

0619 Over-torque
detection
hysteresis
% 1/1 0-100 10

0620 Cooling fan
ON/OFF control
-
- 0: ON/OFF control
1: Always ON
0 6.24.11

0621 Cumulative
operation time
alarm setting
100
hours
0.1/0.1
(=10 hours)
0.0-999.0 876.0 6.24.12

0626 Over-voltage stall
protection level
%
1/1 100-150 *2
6.15.4
6.15.5

0627 Undervoltage
trip/alarm
selection
- - 0: Alarm only
(detection level 64% or less)
1: Tripping
(detection level 64% or less)
2: Alarm only
(detection level 50% or less, input
AC reactor required)
0 6.24.13

0631 Inverter overload
detection method
- - 0: 150%-60s (120%-60s)
1: Temperature estimation
0 3.5

0632 Electronic-thermal
memory
- - 0: Disabled
1: Enabled
0 3.5
6.24.1

0633 Analog input
break detection
level (VIC)
% 1/1 0: Disabled,
1-100
0 6.24.14

0634 Annual average
ambient
temperature (parts
replacement
alarms)
- - 1: -10 to +10C
2: 11-20C
3: 21-30C
4: 31-40C
5: 41-50C
6: 51-60C
3 6.24.15

0644
Operation
selection of
analog input break
detection (VIC)
- - 0: Tripping
1: Alarm only (Coast stop)
2: Alarm only (f649 frequency)
3: Alarm only (Maintain running)
4: Alarm only (Deceleration stop)
0 6.24.14

0645
PTC thermal
selection
- - 1: Tripping
2: Alarm only
1 6.24.16

0646
PTC detection
resistor value
Ω 1/1
100-9999 3000

0648
Number of starting
alarm
10000
times
0.1/0.1
0.0-999.0
999.0
6.24.17

0649
Fallback
frequency
Hz 0.1/0.01 ll- 0.0
6.24.14

0650 Forced fire-speed
control selection
- - 0: Disabled
1: Enabled
0 6.25

0656
Factory specific
coefficient 6A
- - - -
* 3
*2: Default setting values vary depending on the capacity. Refer to section 11.4.
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
