Toshiba TOSVERT VF-MB1 User Manual

E6581697
K-16
11
Title
Communication
No.
Function
Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0511 Deceleration time
3
s 0.1/0.01 0.0-3600 (360.0) *8 10.0 6.23.2

0512 Acceleration/decel
eration 3 pattern
- - 0: Linear
1: S-pattern 1
2: S-pattern 2
0

0513 Acceleration/decel
eration 2 and 3
switching
frequency
Hz 0.1/0.01 0.0 (disabled)
0.1-
0.0

0515 Deceleration time
at emergency stop
s 0.1/0.01 0.0-3600 (360.0) *8 10.0 6.24.4

0519 Setting of
acceleration/decel
eration time unit
- - 0: -
1: 0.01s unit (after execution: 0)
2: 0.1s unit (after execution: 0)
0 6.23.2
*8: These parameters can be changed to 0.01s unit by setting f519=1.
 Protection parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0601 Stall prevention
level 1
%
(A)
1/1
10-199，
200 (disabled)
150
6.24.2

0602
Inverter trip
retention selection
- - 0: Cleared with power off
1: Retained with power off
0 6.24.3

0603 Emergency stop
selection
- - 0: Coast stop
1: Deceleration stop
2: Emergency DC braking
3: Deceleration stop (f515)
4: Quick deceleration stop
5: Dynamic quick deceleration stop
0
6.24.4

0604 DC braking time
during emergency
stop
s 0.1/0.1
0.0-20.0 1.0

0605
Output phase
failure detection
selection
-
-
0: Disabled
1: At start-up (only one time after
power on)
2: At start-up (each time)
3: During operation
4: At start-up + during operation
5: Detection of cutoff on output side
0
6.24.5

0607 Motor 150%
overload detection
time
s 1/1 10-2400 300 3.5
6.24.1

0608 Input phase failure
detection selection
- - 0: Disabled
1: Enabled
1 6.24.6

0609 Small current
detection
hysteresis
% 1/1 1-20 10

0610 Small current
trip/alarm
selection
- - 0: Alarm only
1: Tripping
0

0611 Small current
detection current
%
(A)
1/1 0-150 0

0612 Small current
detection time
s 1/1 0-255 0
6.24.7

0613 Detection of
output short-circuit
at start-up
- - 0: Each time (standard pulse)
1: Only one time after power on
(standard pulse)
2: Each time (short pulse)
3: Only one time after power on
(short pulse)
0 6.24.8
