E6581697
K-32
11
 Table of input terminal functions 2
Function
No.
Code Function Action Reference
50 HD Operation hold (hold of 3-wire operation) ON: F (forward run), R: (reverse run) held, 3-wire operation
OFF: Deceleration stop
7.2.1
51 HDN Inversion of operation hold (hold of 3-wire
operation)
Inversion of HD
52 IDC PID integral/differential clear ON: Integral/differential clear, OFF: Clear canceled 6.20
53 IDCN Inversion of PID integral/differential clear Inversion of IDC
54 PIDSW PID characteristics switching ON: Inverted characteristics of  selection
OFF: Characteristics of  selection
55 PIDSWN Inversion of PID characteristics switching Inversion of PIDSW
56 FORCE Forced run operation ON: Forced run operation if specified faults are occurred
( frequency)
OFF: Normal operation
6.25
57 FORCEN Inversion of forced run operation Inversion of FORCE
58 FIRE Fire speed operation ON: Fire speed operation ( frequency)
OFF: Normal operation
59 FIREN Inversion of fire speed operation Inversion of FIRE
60 DWELL Acceleration/deceleration suspend signal ON: Acceleration/deceleration suspend
OFF: Normal operation
6.19
61 DWELLN Inversion of acceleration/deceleration
suspend signal
Inversion of DWELL
62 KEB Power failure synchronized signal ON: Deceleration stop with synchronizing when power failure
OFF: Normal operation
6.15.2
63 KEBN Inversion of power failure synchronized
signal
Inversion of KEB
64 MYF Logic sequence function trigger signal ON: Trigger(start operation) signal of logic sequence function
OFF: Normal operation
6.36
65 MYFN Inversion of logic sequence function trigger
signal
Inversion of MYF
70, 71 Factory specific coefficient - *1
74 CKWH Integrating wattmeter(kwh) display clear ON: Integrating wattmeter(kwh) monitor display clear
OFF: Disabled
6.31
75 CKWHN Inversion of integrating wattmeter display
clear
Inversion of CKWH
76 TRACE Trace back trigger signal ON: Trigger(start) signal of trace function
OFF: Disabled
6.30
77 TRACEN Inversion of trace back trigger signal Inversion of TRACE
78 HSLL Light-load high-speed operation prohibitive
signal
ON: Light-load high-speed operation prohibited
OFF: Light-load high-speed operation permitted
6.17
79 HSLLN Inversion of light-load high-speed operation
prohibitive signal
Inversion of HSLL
80 HDRY Holding of RY-RC terminal output ON: Once turned on, RY-RC are held on.
OFF: The status of RY-RC changes in real time according to
conditions.
7.2.2
81 HDRYN Inversion of holding of RY-RC terminal
output
Inversion of HDRY
82 HDOUT Holding of OUT-NO terminal output ON: Once turned on, OUT-NO are held on.
OFF: The status of OUT-NO changes in real time according
to conditions.
83 HDOUT
N
Inversion of holding of OUT-NO terminal
output
Inversion of HDOUT
88 UP Frequency UP ON: Frequency increased
OFF: Frequency increase canceled
6.6.3
89 UPN Inversion of frequency UP Inversion of UP
90 DWN Frequency DOWN ON: Frequency decreased
OFF: Frequency decrease canceled
91 DWNN Inversion of frequency DOWN Inversion of DWN
92 CLR Clear frequency UP/DOWN OFF ¤ ON: Clear frequency UP/DOWN
93 CLRN Inversion of clear frequency UP/DOWN Inversion of CLR
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
