E6581697
K-33
11
Table of input terminal functions 3
Function
No.
Code Function Action Reference
96 FRR Coast stop command ON: Coast stop (Gate OFF)
OFF: Coast stop canceled
3.2.1
97 FRRN Inversion of coast stop command Inversion of FRR
98 FR Forward/reverse selection ON: Forward operation command
OFF: Reverse operation command
7.2.1
99 FRN Inversion of forward/reverse selection Inversion of FR
100 RS Run/Stop command ON: Run command
OFF: Stop command
7.2.1
101 RSN Inversion of run/Stop command Inversion of RS
104 FCHG Frequency setting mode forced switching ON: f207 (f200=0)
OFF: fmod
5.6
105 FCHGN Inversion of frequency setting mode forced
switching
Inversion of FCHG
106 FMTB Frequency setting mode terminal board ON: Terminal board (VIA) enabled
OFF: Setting of
107 FMTBN Inversion of frequency setting mode terminal
board
Inversion of FMTB
108 CMTB Command mode terminal board ON: Terminal board enabled
OFF: Setting of
109 CMTBN Inversion of command mode terminal board Inversion of CMTB
110 PWE Parameter editing permission ON: Parameter editing permitted
OFF: Setting of
6.29.1
111 PWEN Inversion of parameter editing permission Inversion of PWE
120 FSTP1 Fast stop command 1 ON: Dynamic quick deceleration command
OFF: Forced deceleration canceled
(Note that operation is resumed when forced deceleration is
canceled)
5.4.1
121 FSTP1N Inversion of fast stop command 1 Inversion of FSTP1
122 FSTP2 Fast stop command 2 ON: Automatic deceleration
OFF: Forced deceleration canceled
(Note that operation is resumed when forced deceleration is
canceled)
123 FSTP2N Inversion of fast stop command 2 Inversion of FSTP2
134 TVS Traverse permission signal ON: Permission signal of traverse operation
OFF: Normal operation
6.35
135 TVSN Inversion of traverse permission signal Inversion of TVS
136, 137 Factory specific coefficient - *1
140 SLOWF Forward deceleration ON: Forward operation with f383 frequency
OFF: Normal operation
6.18.2
141 SLOWFN Inversion of forward deceleration Inversion of SLOWF
142 STOPF Forward stop ON: Forward stop
OFF: Normal operation
143 STOPFN Inversion of forward stop Inversion of STOPF
144 SLOWR Reverse deceleration ON: Reverse operation with f383 frequency
OFF: Normal operation
145 SLOWRN Inversion of reverse deceleration Inversion of SLOWR
146 STOPR Reverse stop ON: Reverse stop
OFF: Normal operation
147 STOPRN Inversion of reverse stop Inversion of STOPR
148 to 151 Factory specific coefficient - *1
200 PWP Parameter editing prohibition ON: Parameter editing prohibited
OFF: Setting of
6.29.1
201 PWPN Inversion of parameter editing prohibition Inversion of PWP
202
PRWP Parameter reading prohibition ON: Parameter reading / editing prohibited
OFF: Setting of
203 PRWPN Inversion of parameter reading prohibition Inversion of PRWP
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
Note 1: Function No. that are not described in the table above are assigned "No function".
