3.2.2 How to set the frequency
[Example of  setting procedure]: Setting the frequency by the terminal VIA
Panel operation LED display Operation

Displays the output frequency (operation stopped).
(When standard monitor display selection = [output frequency])

Displays the first basic parameter [History ()].

Turn the setting dial, and select "".

Press the center of the setting dial to read the parameter value.
(Standard default: ).

Turn the setting dial to change the parameter value to  (terminal block
VIA).

The parameter value is written. and the parameter value are
displayed alternately several times.
* Pressing the MODE key twice returns the display to standard monitor mode (displaying output frequency).
(1) Setting using the keypad (= or )
: Moves the frequency up : Moves the frequency down
 Example of operating from the panel (=: press in center to save)
Panel operation LED display Operation

Displays the output frequency.
(When standard monitor display selection = [output frequency])

Set the output frequency. (The frequency will not be saved if the
power is turned off in this state.)

Save the output frequency.  and the frequency are displayed
alternately.
 Example of operating from the panel (=: save even if power is off)
Panel operation LED display Operation

Display the output frequency.
(When standard monitor display selection is set as =
[output frequency])

Set the output frequency.
-

The frequency will be saved even if the power is turned off in this
state.
MODE
