E6581386
A-9
1
Grounding terminal
(M12 screw)
M12 screw
Grounding
capacitor
switching screw
M12 screw
M4 screw
3) Control circuit terminal block
The control circuit terminal block is common to all equipment.
PWR-P24/PLC Shorting bar
Control circuit terminal bloc
k
screw size: M3
4-wire RS485
connector
For details on all terminal functions, refer to Section 2.3.2.
VFPS1-4630KPC
