Title Function Adjustment range Default setting
Block write data 2 Ditto
Block read data 1
:Deselect
:Status information
:Output frequency
:Output current
:Output voltage
:Alarm information
:PID feedback value
:Input terminal board monitor
:Output terminal board monitor
:VI/II terminal board monitor
:RR/S4 terminal board monitor
:RX terminal board monitor
:Input voltage (DC detection)
:Speed feedback frequency
:Torque
:MY monitor 1
:MY monitor 2
:MY monitor 3
:MY monitor 4
:Free notes
:Rotational speed
Block read data 2 Ditto
Block read data 3 Ditto
Block read data 4 Ditto
Block read data 5 Ditto
Free notes ~
* : No action ... No action is taken even if a timeout occurs.
Alarm ........ An alarm goes off if a timeout occurs.
The message “” blinks at the left end of the operation panel.
Trip ............ The inverter trips when a communication time-over occurs.
The message “” blinks on the operation panel.
Note: Changes to the parameters , and do not take effect until the power is turned off and
then on again.
6.34.2 Open network option
~ : For Ethernet Communication option
~ : MAC address data 1~6
~ : Device name data 1~8
: Address monitor (Modbus plus)
: Command selection (Modbus plus)
: Number of command (Modbus plus)
: Number of monitors (Modbus plus)
: Command station (Modbus plus)
: Baud rate (Ethernet)
: Baud rate monitor right port (Ethernet)
: Baud rate monitor left port (Ethernet)
: - (Reservation)
~ : Communication option settings 1 to 7
~ : Communication option settings 8 to 13
: Communication2 time-out condition selection
: Disconnection detection extended time
: Inverter operation at disconnection
: Preset speed operation selection
, : Selection of monitoring
: Motor pairs of poles for communication
For details, refer to Instruction Manual (E6581281, E6581343) specified in Section 6.36.
