5.15 Changing the display unit % to A (ampere)/V (volt)
 : Current/voltage unit selection
 Example of setting
During the operation of the VFPS1-2037PL (rated current 16.6A) at the rated load (100% load), units are displayed
as follows:
1) Display in percentage terms 2) Display in amperes/volts




Output current:
16.6
A
DC voltage:
200V
(Converted into
A
C voltage)
DC voltage:
100%
Output current:
100%


[Parameter setting]
Title Function Adjustment range Default setting
 Current/voltage unit selection
: %
: %  A (ampere)/V (volt)

• Function
These parameters are used to change the unit of monitor display.
% A (ampere)/V (volt)
Current 100% = Inverter’s rated current
200V-class voltage 100% = 200Vac
400V-class voltage 100% = 400Vac
* The  converts the following parameter settings:
• A display Current monitor display
Setting of electronic thermal protection level 1/2 , , , 
DC braking current 
Stall prevention level 
• V display Voltage monitor display
V/f 5-point setting , , , , 
Note: Base frequency voltage 1, 2 (, ) is always displayed in the unit of V.
