E6581386
I-9
9
Table 5 AIC, Fuse and Wire sizes
Voltage
class
Applicable
motor
[kW]
Inverter model
UL
output current
(A) *1, *2
AIC (A)
(Interrupting
capacity)
Fuse class and
current
(A)
Input wire sizes of
power circuit
(AWG) *3
Output wire sizes
of power circuit
(AWG) *3
Grounding
wire
(AWG) *3
0.4 VFPS1-2004PL 2.5 (
=
) AIC 5000A CC 7Amax
.
14 14 14
0.75 VFPS1-2007PL 4.8 (
=
) AIC 5000A J 15Amax
.
14 14 14
1.5 VFPS1-2015PL 7.8 (
=
) AIC 5000A J 25Amax
.
14 14 14
2.2 VFPS1-2022PL 11.0 (
=
) AIC 5000A J 25Amax. 12 12 14
3.7 VFPS1-2037PL 17.5 (
=
) AIC 5000A J 45Amax
.
10 10 12
5.5 VFPS1-2055PL 25.3 (
=
) AIC 5000A J 60Amax
.
8 8 10
7.5 VFPS1-2075PL 32.2 (
=
) AIC 5000A J 70Amax
.
8 8 10
11 VFPS1-2110PM 48.3 (
=
) AIC 5000A J 90Amax
.
4 4 10
15 VFPS1-2150PM 62.1 (
=
) AIC 5000A J 110Amax
.
4 4 10
18.5 VFPS1-2185PM 74.8 (
=
.
) AIC 5000A J 125Amax
.
3 3 8
22 VFPS1-2220PM 88 (
=
.
) AIC 5000A J 150Amax
.
2 2 8
30 VFPS1-2300PM 114 (
=
.
) AIC 5000A J 200Amax
.
2/0 2/0 6
37 VFPS1-2370PM 143 (
=
.
) AIC 5000A J 225Amax
.
3/0 3/0 6
45 VFPS1-2450PM 169 (
=
.
) AIC 10000A J 300Amax
.
4/0 4/0 6
55 VFPS1-2550P 221 (
=
.
) AIC 10000A J 350Amax
.
3/0×2 3/0×2 1/0
75 VFPS1-2750P 285 (
=
.
) AIC 10000A J 350Amax
.
4/0×2 4/0×2 1/0
200V
class
90 VFPS1-2900P 359 (
=
.
) AIC 10000A J 450Amax
.
250MCM×2 250MCM×2 1/0
0.75 VFPS1-4007PL 2.1 (
=
) AIC 5000A CC 6Amax
.
14 14 14
1.5 VFPS1-4015PL 3.4 (
=
) AIC 5000A CC 12Amax. 14 14 14
2.2 VFPS1-4022PL 4.8 (
=
) AIC 5000A J 15Amax. 14 14 14
3.7 VFPS1-4037PL 7.6 (
=
) AIC 5000A J 25Amax. 12 12 14
5.5 VFPS1-4055PL 11.0 (
=
) AIC 5000A J 40Amax. 10 10 12
7.5 VFPS1-4075PL 14. 0 (
=
) AIC 5000A J 40Amax. 10 10 12
11 VFPS1-4110PL 21.0 (
=
) AIC 5000A J 60Amax. 8 8 10
15 VFPS1-4150PL 27.0 (
=
) AIC 5000A J 70Amax. 6 6 10
18.5 VFPS1-4185PL 34.0 (
=
) AIC 5000A J 70Amax. 6 6 10
22 VFPS1-4220PL 40.0 (
=
) AIC 5000A J 80Amax. 6 6 10
30 VFPS1-4300PL 52.0 (
=
) AIC 5000A J 90Amax. 4 4 10
37 VFPS1-4370PL 65.0 (
=
.
) AIC 5000A J 110Amax. 3 3 8
45 VFPS1-4450PL 77.0 (
=
.
) AIC 10000A J 150Amax. 1 1 8
55 VFPS1-4550PL 96.0 (
=
.
) AIC 10000A J 175Amax. 1/0 1/0 6
75 VFPS1-4750PL 124.0 (
=
.
) AIC 10000A J 225Amax. 3/0 3/0 6
90 VFPS1-4900PC 179.0 (
=
.
) AIC 10000A J 250Amax. 1/0×2 1/0×2 2
110 VFPS1-4110KPC 215.0 (
=
.
) AIC 10000A J 300Amax. 2/0×2 2/0×2 2
132 VFPS1-4132KPC 259.0 (
=
.
) AIC 10000A J 350Amax. 4/0×2 4/0×2 1
160 VFPS1-4160KPC 314.0 (
=
.
) AIC 18000A J 400Amax. 250MCM×2 250MCM×2 1
220 VFPS1-4220KPC 427.0 (
=
.
) AIC 18000A J 500Amax. 350MCM×2 350MCM×2 2/0
250 VFPS1-4250KPC 481.0 (
=
.
) AIC 18000A J 600Amax. 250MCM×3 250MCM×3 2/0
280 VFPS1-4280KPC 550.0 (
=
.
) AIC 18000A J 600Amax. 300MCM×3 300MCM×3 3/0
315 VFPS1-4315KPC 616.0 (
=
.
) AIC 30000A T 800Amax. 350MCM×3 350MCM×3 3/0
400 VFPS1-4400KPC 759.0 (
=
.
) AIC 30000A
Semiconductor
900Amax.
350MCM×4 350MCM×4 4/0
500 VFPS1-4500KPC 941.0 (
=
.
) AIC 42000A J 600A × 2 max. 500MCM×2×2 500MCM×4 250MCM
400V
class
630 VFPS1-4630KPC 1188.0 (
=
.
) AIC 42000A T 800A × 2 max. 500MCM×3×2 500MCM×5 350MCM
*1: UL output current is different from unit rating output current.
*2: The value of the UL rated output current is applicable when the carrier frequency (
) is less than the value
shown in the table.
*3: The cables used must be 75
℃ copper cables within 40℃ ambient temperature.
9.2.4 Caution as to the protection of motors from overload
When using the inverter’s thermal protection function to protect the motor from overload, read the instruction manual
included with the inverter carefully and set parameters according to the specifications of the motor used.
When using the inverter to control the operation of multiple motors, install an overload relay for each individual motor.
