E6581386
A-2
1
1. 3 Structure of the main body
1.3.1 Names and functions
1) Outside view
Be sure to close the
cover before starting the
operation to prevent
persons from touching
the terminal in error.
Control circuit
terminal cover
Be sure to attach the
cover before starting the
operation to prevent
persons from touching
the terminal in error.
Main circuit terminal
cover
Operation panel
Inverter type and
production No. are on the
back side of the control
circuit terminal cover.
[Front panel]
Cooling fan
Wiring port
Protective cover on the top [Note]
Ventilation slit
Name plate
[Bottom view] [Side view]
Note: Remove this cover when installing the inverter side by side with other inverters where the ambient temperature will rise
above 40°C. For more details, refer to Section 1.4.4.
To Next Page
