5
Chapter 1
Get to Know Your Devices
Item Description
1 Sync Button
For pairing the Controller and the Satellite and starting WPS process.
Press the button for 1 second to start a WPS process, press for 5 seconds to
start a synchronization process.
2 WAN/LAN Port
Combined with WAN/LAN interface capabilities, which can be used to connect
the device to the Internet or Ethernet network devices.
3 LAN Port For connecting the your PC or other Ethernet network devices.
4 ON/OFF Button
The switch for the power. Press it to power on or off the device.
ON
OFF
5 Power Port For connecting the device to a power socket via the provided power adapter.
6 Rest Button
Press and hold down for a few seconds to reset the device into factory default
settings.
