TP-Link TD854W

Error! AutoText entry not defined. Error! AutoText entry not defined. User Guide
46
Figure 4-26
 RIP: Select to enable the RIP function or not. Click the Apply button to save your
configuration.
 Interface: Select the interface on which you want to enable RIP.
 Recv Version: Indicate the RIP version in which information must be passed to the device. It
can be accepted into its routing table.
 Send Version: Indicate the RIP version this interface will use when it sends its route
information to the other device.
Click the Add button to add a RIP configuration to the Rip Config List. Click the Delete button to
delete it.
The RIP Config List shows the current RIP setting of the device.

Note:
After adding a new entry, a Save button will appear on the left panel. You need to click the Save
button to make your changes take effect.
4.3.2 NAT
4.3.2.1 DMZ
Choose “Advanced→NAT→DMZ”, you can configure the DMZ host in the screen as shown in
Figure 4-27.
A DMZ (demilitarized zone) is a host between a private local network and the outside public
network. It allows a single host on your LAN to expose all of its ports to the Internet. Users of the
public network outside the company can access to the DMZ host.
