TP-Link TL-SG2216WEB - Port Default Priority; 802.1 P Priority Class

59
Web Smart Gigabit Switch Family User's Guide
TL-SG2216WEB/TL-SG2224WEB
entering from the port of the switch are forwarded in the corresponding
priority queue.
Further Explanation
When priority rule is congured as "weighted", a 1,2,4,8 weighting is applied to
forward these four classes of packets.
5.3.6.3 Port Default Priority
This page is revealed when the “IEEE802.1p” mode is congured. When a
switch port receives an untagged frame (a frame without priority tag), the port's
default priority tag will be inserted into the frame before any other process.
Figure 5-42 Port Default Priority
Port: Indicates the switch port number.
Default Priority Tag: Indicates 802.1p tag being inserted into untagged
frames.
5.3.6.4 802.1p Priority Class
This page is revealed when the “IEEE802.1p” mode is congured. As shown
below:


