54
Web Smart Gigabit Switch Family User's Guide
TL-SG2216WEB/TL-SG2224WEB
Notice:
If any Trunk has be set, the Trunk can be congured, but member ports of the
Trunk is not able to be congured and in the elds it display the parameters of
the Trunk they belong to.(see port1 and 2 in the gure for example).
5.3.4.4 Tag VLAN Setting
This page displays when the switch is in Tag VLAN mode, it congures each
VLAN and is affected by the global setting of the ports, it contains the following
elds:
Figure 5-36 Tag VLAN Setting
VLAN: The VLAN number. Select the number of the VLAN you want to
congure here.
