98
Chapter 6
Congure the Router as a Repeater
• Channel - The current wireless channel.
• Channel Width - The current wireless channel width.
• MAC Address - The physical address of the router.
• WDS Status - The status of the WDS connection is displayed.
• System Up Time - The length of the time since the router was last powered on or
reset.
Click Refresh to get the latest status and settings of the router.
6. 2. Operation Mode
1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
router.
2. Go to Operation Mode.
3. Select Repeater/Bridge and click Save.
6. 3. Network
6. 3. 1. LAN
1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
router.
2. Go to Network > LAN.
3. Configure the IP parameters of the LAN and click Save.
