9.2.2 When A is set to Pond, with no extra B data
1. Press in normal display mode. The display should now look like this…
10.00ppM 2.76mS 7.00pH 25.0
o
c
Log#1, Pond#1 31/12 12:00:00
2. Use the numeric keypad to key in the Pond number, then press to record all parameters,
Date, Time and the Pond number into the Logger memory. This will be labelled as reading
number 1.
Alternatively, press to quit without recording the reading.
3. Repeat steps 1 & 2 as often as required.
The Pond number will automatically increment by one from the last recorded reading.
The maximum number of readings that can be stored in the Logger with this A & B Data Input
setting is 1632.
9.2.3 When A is set to Pond, and B is set to data
1. Press in normal display mode. The display should now look like this…
10.00ppM 2.76mS 7.00pH 25.0
o
c
Log#1, Pond#1 31/12 12:00:00
2. Use the numeric keypad to key in the Pond number, then press to record all parameters,
Date, Time and the Pond number into the Logger memory. This will be labelled as reading
number 1.
Alternatively, press to quit without recording the reading.
3. The 90-FL now proceeds to the B data entry screen…
Data Recorded, Now Input B or Press Menu
Enter Data B:0
Use the numeric keypad to key in up to four characters for the “B” data item. The decimal point
is available. Press to record the “B” data item, or press to quit. Quitting at this point
records a Zero as the “B” data item.
4. Repeat steps 1 to 3 as often as required.
The Pond number will automatically increment by one from the last recorded reading.
The maximum number of readings that can be stored in the Logger with this A & B Data Input
setting is 1632.
