TPS 90-FL - Recalling Readings from the Logger

41
9.4 Recalling Readings from the Logger
To recall records from the Logger onto the 90-FL display…
1. Select the Logger menu ( →→ F3:Logger)
2. Select F1:Recall from the menu.
Record number 1 is now displayed.
The following example shows the display when the A & B Data Input function was switched
off during logging…
10.00ppM 2.76mS 7.00pH 25.0
o
c
Log#1 F2:↑↑ F4:↓↓ 31/12 12:00:00
The following example shows the display when “A” and “B” were both set to data during
logging…
10.00ppM 2.76mS 7.00pH 25.0
o
c
Log#1 A=1234 B=1234 31/12 12:00:00
3. Press to display the next record.
Press to display the previous record.
Press and hold or to scroll continuously through the readings.
To display a specific record, type in the desired record number using the Numeric Keypad and
press .
Press to send the displayed record to the RS232 port.
