Trace Engineering DR Series Owner’s Manual - Version 3.2 - 9/7/98 - Page 25
Minimum Recommended Wire Sizes
MODEL AC INPUT AC OUTPUT
120 VAC 220-240 VAC 120 VAC 220-240 VAC
DR1512 10 gauge 14 gauge 12 gauge 16 gauge
DR2412 6 gauge 10 gauge 10 gauge 14 gauge
DR1524 10 gauge 14 gauge 12 gauge 16 gauge
DR2424 6 gauge 10 gauge 10 gauge 14 gauge
DR3624 6 gauge
Not
Recommended
8 gauge
Not
Recommended
Table 5, Minimum Recommended Wire Sizes
NOTE: Consult NEC (National Electric Code) for actual wire sizes required for your specific
installation.
Important Precautions
The output side of the inverter’s AC wiring should at no time be connected to public power or a
generator. This condition is far worse than a short circuit. If the unit survives this condition, it will shut
down until corrections are made.
Installation should ensure that the inverter’s AC output is, at no time, connected to its AC input.
Review the installation diagrams included before you start making connections.
Ground Fault Interrupting Outlets (GFI’s)
Trace Engineering has tested the following GFI’s and found them to work satisfactorily with our
inverters:
LEVITON 6599
PASS & SEYMOR 1591RI 4A957
ACE Hardware ACE 33238 and 33236
