INSTALLATION
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
27
Copper Compression Lugs: Commonly available at hardware, welding, and auto parts retailers,
compression lugs must be crimped onto each cable using an appropriate crimping tool. These lugs
are not available from Trace Engineering. Suggested sources and part numbers are:
Hollingsworth, Pompano Beach, FL 305-979-2050
Part # Description
TL3061 2/0 Ring Terminal
TL3062 4/0 Ring Terminal
H40 8 AWG to 250MCM Air-Operated Crimping Tool
Thomas & Betts
K973 2/0 Ring Terminal
M973 4/0 Ring Terminal
RJ737 2/0 Insulated Ring Terminal
RL737 4/0 Insulated Ring Terminal
TBM6 Hand Operated Crimping Tool (order dies separately)
Dies: #11809 for crimping 2/0 non-insulated lugs
#11811 4/0 non-insulated lugs
#11826 2/0 insulated lugs
#11828 4/0 insulated lugs
Mechanical Lugs: Aluminum mechanical lugs are available from electrical hardware suppliers and
do not require crimping. Suggested sources and part numbers are:
Part # Description
ILSCO
TA-2/0 2/0 Lug
TA-250 (preferred) 250 MCM Lug
Thomas &Betts
62205 2/0 Lug
62212 250 MCM Lug
Panduit
LAMA2/0-14 2/0 Lug
LAMA250-56. 250 MCM Lug
Ground Cable Connection
You probably noticed that the Trace Legend Series II inverter/chargers have a third battery terminal
labeled Vehicle Chassis Ground (the green terminal on the left side of the unit). The purpose of this
third terminal is be sure that all DC load current into or out of the battery bank will flow through the
internal shunt of the inverter. The internal shunt is connected between the black battery negative
terminal and the green chassis ground terminal of the inverter (See Figure 3, DC Wiring Diagram on
Page 30.)
Because all DC loads in a vehicle are generally connected to a common chassis ground and not
directly to the battery negative (in a negative ground system), all DC current in the system will at
some point pass through the chassis and then into the battery bank. If the inverter is in this loop the
net current flow is easily monitored. Thus, the RC7 remote controls battery fuel gauge feature is
