APPENDIX E: DIMENSIONS
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
77
Appendix E: Dimensions
12.375”
13.15"
P
N
2
3
7
3
CAUTION
7.25
"
Note: teminals and covers add 1 1/2” to length
