APPENDIX C: REFERENCE TABLES & GRAPHS
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
71
Maximum Fuse Rating in Free Air
Cable Size Rating in Free Air Maximum Fuse Size
# 2 AWG 170 amps maximum 175 Amp
00 AWG 265 amps maximum 300 Amp
0000 AWG 360 amps maximum 400 Amp
Recommended Minimum AC Wire Sizes
Inverter Model 120 VAC Input 120 VAC Output
L2012 10 gauge 12 gauge
L2512 8 gauge 10 gauge
L3012 8 gauge 10 gauge
Common Battery Charging Rates
Typical BULK and FLOAT Setpoints for Common Battery Types (12VDC System)
Battery Type Bulk Volts Float Volts
Gelled Lead-Acid (sealed ) 14.1 volts 13.5 volts
Liquid Lead-Acid (not-sealed) 14.5 volts 13.4 volts
