INSTALLATION
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
29
inverter. The fuses are available in 110, 200, 300, and 400 amp sizes. Contact your Trace dealer to
order; see the Options section of this manual for more information.
Note
To order a fuse with fuse block from a Trace Dealer, order part number TFB
followed by the desired fuse size in amps (i.e. TFB 400). When ordering
replacement fuses, the part number is TF followed by the size in amps of the
desired fuse (i.e. TF400).
Table 2, Current Carrying Ability of Wire In Free Air at 75°C
Cable Size Maximum Rating
Maximum
# 2 AWG 170 amps 175 Amp
00 AWG 265 amps 300 Amp
0000 AWG
360 amps 400 Amp
