APPENDIX D: SPECIFICATIONS
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com Page
75
Appendix D: Specifications
MODEL L2012 L2512 L3012
Continuous Power @ 25°C 2000 Watts 2500 Watts 3000 Watts
Continuous AC Current 16.6 amps 20.8 amps 28 amps
Efficiency (Maximum) 94% 94% 94%
Adjustable Charge Rate 10-100 amps 12-120 amps 14-140 amps
Unit Weight 45lbs(20.5kg) 50lbs(22.7kg) 60lbs(27.2kg)
DC Input Current Consumption
Search Mode 0.055 amps 0.070 amps 0.080 amps
Full Voltage (search defeated) 0.550 amps 0.600 amps 0.650 amps
At Rated Power 200 amps 250 amps 300 amps
Short Circuit 600 amps 800 amps 900 amps
The following specifications apply to all models:
Nominal Input Voltage 12VDC
Input Voltage Range 10.2-15.5VDC
Auto Low Battery Protection (LBCO) 11.1VAC or defeated
with RC7 remote
Voltage Regulation- Maximum ±5%
Voltage Regulation- Typical ±2.5%
Output Waveform Modified Sine Wave
Power Factor allowed -1 to +1
Frequency Regulation 60Hz ± .04%
Standard Output Voltage 120 VAC
Adjustable Load Sensing 5 to 40 Watts or defeated
Forced Air Cooling Automatic Variable Speed Fan
Automatic Transfer Relay 30 amps at 120VAC
Number of Charging Profiles 2 (liquid lead acid or gel cell)
Three Stage Charging yes – Bulk, Float, Absorption
Battery Temperature Compensation (BTS) Optional: BTS/15 (15 foot cable included)
Remote Control Optional: RC6- Bargraph Volt/Ammeter On/Off
RC7- Full Function LED Display
Environmental Characteristics
Operating Ambient Temp 0°C to +50°C
Non-operating Temp -55°C to +75°C
Altitude Operating 15,000 feet
Altitude Non-operating 50,000 feet
Dimensions 13.15” x 7.25” x 14.3”
33.3cm x 18cm x 35.2cm
Mounting Shelf mount only
