Trace Engineering Legend User Manual

INSTALLATION
Trace Engineering Co. Inc. Tel (360) 435-8826 Part Number 3179
5916 195
th
Street, NE Fax (360) 435-2229 Effective August 6, 1998
Arlington, WA 98223 USA www.traceengineering.com
Page
30
Figure 3, DC Wiring Diagram
As an option, you may
directly connect between
DC load center negative
and vehicle chassis
ground (green) terminal of
inverter
Out to DC loads
Vehicle Chassis
Ground (green)
DC Load
Distribution
Panel
Fuse Block
Internal Shunt
NOTE: In accordance with
NEC code, the fuse block
must be no more than 18
inches from the battery
bank.
