Trace2O HT1000 - Instrument (Exploded Drawing)

HT1000_0.5 09/2015
7
2.1.4 Instrument (exploded drawing):
(A) screws
(B) battery compartment cover
(C) notch
(D) batteries: 4 batteries (AA/LR6)
(E) seal ring
(F) instrument back
(B) battery
compartment
cover
(E) seal ring
(F) instrument back
(A) screws
(C) notch
(D) batteries
CAUTION:
To ensure that the instrument is water proof:
• seal ring (E) must be in position
• battery compartment cover (B) must be fixed with the four screws
