Edit the default presence detection zone
The Guidelines to edit the zones illustrate the advised size and position of a presence detection zone.
• Click-and-drag anywhere in the zone to move the zone.
• Put the cursor on a zone point.
• Click-and-drag the zone point to position it.
• Position the other zone points accordingly.
The zone should be made direction sensitive only in situations where vehicles in the opposite direction may cause
unwanted detection.
• Double-click the direction point to define the direction of the zone.
If you wish to delete the zone direction: double-click the direction point.
TrafiCam PC Tool assigns an output to the zone automatically. The number in the zone refers to the assigned
output. To change the assigned output: right-click the zone and select an output from the drop-down menu.
A zone is characterised by its Zone ID. To verify the zone ID: right-click the zone, the zone ID is displayed.
Add a zone
• Right-click anywhere on the sensor image except on a zone.
• Click the Add Zone pop-up.
• Edit the zone as described previously.
You can place up to 8 presence detection zones.
To delete a zone: right-click the zone and click the Delete Zone pop-up.
Set the zone to detect stationary vehicles only (stop detection mode)
• Choose Tools > Advanced Settings > Zone information.
• To set all zones: click All Zones and select Stop as the Detection Mode.
• To set one zone: select the zone and select Stop as the Detection Mode.
Set the output relation
You assign an OR or AND relation to the TrafiCam outputs:
• OR: the output changes status when presence is detected on at least one zone of the output.
• AND: the output changes status when presence is detected on all zones of the output.
• Select Outputs from the Edit menu.
• Select Output Relation.
• Use the arrow keys to set the output relation.
Default: Or
Selection: Or, And
Both the assigned and the unassigned outputs will close upon presence detection. If you wish to change the output
mode, proceed as follows:
Change the output mode of the assigned outputs
• Select Outputs from the Edit menu.
• Select Output Mode.
• Use the arrow keys to set the mode.
