16WX
TrafiCam with TI (9 wires)
Default: Close on Event
Selection: Close or Open on Event
Change the output mode of the unassigned outputs
• Select Outputs from the Edit menu.
• Select Unassigned Outputs.
• Use the arrow keys to set the mode.
Default: Close
Selection: Close or Open
Activate the setup of TrafiCam
• Click Send Configuration from the File menu.
The configuration is sent to the TrafiCam sensor. This process is displayed in the status bar. After sending
TrafiCam PC Tool requests and displays the parameters of the activated setup.
TrafiCam starts a learning cycle. The learning cycle takes a few minutes. During the learning cycle all presence
detection zones are active and the outputs change their status accordingly.
When you View the detection a message will indicate that TrafiCam is learning. After the learning cycle the system
becomes operational.
