25WX
TrafiCam with TI (9 wires)
10.Hardware specification TrafiCam
CAMERA
CMOS, black & white, sensor 1/3”, resolution 640x480, frame rate 30 FPS
LENS TYPE > Wide angle Narrow angle
DIMENSIONS
L x H x W: 45 cm x 16 cm x 10 cm mounted vertically
41 cm x 18 cm x 10 cm mounted horizontally
Mass (including mounting bracket, excluding cable): 600 g
Sensor diameter: 10 cm
MATERIALS
Sensor
Front and back shell: polycarbonate
Mid section: fibre reinforced polyamide
Mounting bracket: fibre reinforced polyamide
Tube: aluminium
COMMUNICATION
RS485 service port for configuration
OUTPUTS
4 optical coupled dry contacts; Imax = 50 mA, Pmax = 300 mW, Umax = 48 VDC
POWER SUPPLY VOLTAGE INPUT
12-26 V AC/DC
POWER CONSUMPTION
85 mA @ 12 V DC (1,2 W)
50 mA @ 24 V DC (1,2 W)
ENVIRONMENTAL
Temperature range: between - 34°C and +80°C
0 to 95% relative humidity, non-condensing
Housing: waterproof to IP67
Materials: weatherproof, UV-resistant
REGULATORY
EMC: Electromagnetic Compatibility - 204/108/EG
FCC: FCC part 15 Class A
NEMA: NEMA II Shock and vibration
Focal distance 3,0 mm 8,0 mm
Field of view - horizontal 95° 32°
Field of view - vertical 65° 22°
Field of view - diagonal 103° 39°
