Traficon TrafiCam - Connector Pinouts and LED Indicators; CN1, CN2, and LED Indicator Code

5WX
TrafiCam with TI (9 wires)
The tables below illustrate the pinout of the connectors CN1 and CN2 and the indicator code of the TrafiCam LED.
Pinout of connector CN1 Pinout of connector CN2
Pin Description Pin Description
+ + Power supply 1 Output 1
- - Power supply 2 Output 2
Grounding 3 Output 3
A RS-485A 4 Output 4
B RS-485B Ref Common output
LED Indication
On (off)
Flashing
Single flash
Double flash
Triple flash
Off (permanently)
Vehicle presence detection (no detection)
TrafiCam in boot mode
Failsafe mode - detection recall
Failsafe mode - quality recall
TrafiCam is learning
No power
