Trane Technologies Agility HDWA PC 747 - Adaptive Frequency Drive

12
HDWA-SVX002C-EN
Figure 4. Typical Agility chiller component location (back view)
Compressor Discharge Check Valve
Relief Valves
Condenser
Water Outlet
Condenser
Water Inlet
Evaporator
Water Outlet
Evaporator
Water Inlet
Evaporator
Compressor Motor
Bearing Controller
Compressor
B
ACK
Output Filter
(200T Only)
Adaptive Frequency Drive
Figure 5. Assembly transformer options
Fans
Auto-transformer
Figure 6. Assembly harmonic filter options
Capacitors
Capacitors
Contactor
Inductor
General Information
