Appendix B: Chiller Installation Completion and
Request for Trane Service
Important: A copy of this completed form must be
submitted to the Trane Service Agency that
will be responsible for the start-up of the
chiller. Start-up will NOT proceed unless
applicable items listed in this form have been
satisfactorily completed.
To:
Trane Service Office:
S.O. Number:
Serial Numbers:
Job/Project Name:
Address:
The following items
are being installed
and will be completed by:
Important: Start-up must be performed by Trane or an
agent of Trane specifically authorized to
perform start-up and warranty of Trane
®
products. Contractor shall provide Trane (or an
agent of Trane specifically authorized to
perform start-up) with notice of the scheduled
start-up at least two weeks prior to the
scheduled start-up. Equipment not started
by Trane is not warranted by Trane.
Check box if the task is complete or if the answer is “yes”.
1. Chiller
☐ Installation meets foundation requirements.
☐ In place and piped.
☐ Isolation pads installed.
Note: Do not insulate the Agility™ chiller or adjacent
piping prior to the chiller commissioning by
Trane service personnel. The contractor is
responsible for any foreign material left in the
unit.
2. Piping
Chilled water piping connected to:
☐ Evaporator
☐ Air handling units
☐ Pumps
☐ Flow switch or flow proving device installed (if not
factory-provided)
Condenser piping connected to:
☐ Condenser
☐ Pumps
☐ Flow switch or flow proving device installed (if not
factory-provided)
☐ Cooling tower
Additional piping:
☐ Make-up water connected to cooling tower
☐ Water supply connected to filling system
☐ Does unit have freeze inhibitor? If unit has freeze
inhibitor:
☐ Verify type and concentration correct per unit
submittal
☐ Calculate and record freeze point of the
solution: ___________ (specify °F or °C)
☐ Systems filled
☐ Pumps run, air bled from system
☐ Strainers installed in entering water piping
(evaporator and condenser) and cleaned
☐ Relief valve ventilation piping installed (as
applicable)
3. Flow balancing valves installed
☐ Leaving chilled water
☐ Leaving condenser water
☐ Proper porting to measure flow and balance
4. Gauges, thermometers, and air vents
☐ Installed on both sides of evaporator
☐ Installed on both sides of condenser
5. Wiring
☐ Wire size per submittal and NEC 310-16
☐ Full power available
☐ External interlocks (flow switch, pumps auxiliary,
etc.)
☐ Chilled water pump (connected and tested)
☐ Condenser water pump (connected and tested)
☐ Cooling tower fan rotation checked
☐ 115 Vac power available for service tools (as
required)
☐ All controls installed and connected
☐ Indicate type of power distribution grounding
☐ If unit was disassembled for installation, all
interconnecting wiring reinstalled
☐ Indicate power distribution grounding type:
☐ Solidly Grounded (Center Ground Wye)
-or-
